90° Angle Connector for Seismic Bracket

I. Product Overview

The 90° angle connector, commonly referred to as L-type right-angle connector or 90° angle bracket, is a core connecting fitting for prefabricated seismic supports and factory-finished hangers & supports. It serves for vertical 90° connection of two C-channel steel sections, enabling right-angle assembly among support uprights, cross arms and diagonal braces. No on-site welding is required; connection is completed by mechanical bolt assembly, complying with the load-bearing requirements of electromechanical seismic codes.

II. Main Applications

90° splicing between C-channel uprights and transverse channels to form support frames;
Right-angle transition at joints between seismic diagonal braces and main supports;
Corner reinforcement for factory-made hangers and supports of pipelines, air ducts and cable trays;
Assembly of seismic supports for electromechanical pipelines in utility tunnels and basements;
Right-angle connection for photovoltaic supports and energy storage equipment supports.

III. Product Advantages

Standard 90° bending forming with precise angle, ensuring controllable installation perpendicularity;
Reinforced bent structure featuring high load capacity and resistance to deformation under seismic conditions;
Compatible with spring nuts and T-bolts for rapid assembly and improved construction efficiency;
Modular design allowing easy disassembly and adjustment during later pipeline renovation;
Uniform galvanized coating for rust and corrosion resistance, suitable for long-term building service.

IV. Key Supporting Construction Requirements

Matching components: M12 bolts, spring nuts, flat washers and spring lock washers;
Installation torque: Normally 4～8N·m (to be implemented in accordance with test reports);
Reinforced 8-hole type is preferred for critical seismic joints; non-standard thin-gauge angle brackets are prohibited;
All load-bearing connections shall be fully tightened without loose joints.
